AutoMM for Image + Text + Tabular - Quick Start#
AutoMM is a deep learning “model zoo” of model zoos. It can automatically build deep learning models that are suitable for multimodal datasets. You will only need to convert the data into the multimodal dataframe format and AutoMM can predict the values of one column conditioned on the features from the other columns including images, text, and tabular data.
import os
import numpy as np
import warnings
warnings.filterwarnings('ignore')
np.random.seed(123)
Dataset#
For demonstration, we use a simplified and subsampled version of PetFinder dataset. The task is to predict the animals’ adoption rates based on their adoption profile information. In this simplified version, the adoption speed is grouped into two categories: 0 (slow) and 1 (fast).
To get started, let’s download and prepare the dataset.
download_dir = './ag_automm_tutorial'
zip_file = 'https://automl-mm-bench.s3.amazonaws.com/petfinder_for_tutorial.zip'
from autogluon.core.utils.loaders import load_zip
load_zip.unzip(zip_file, unzip_dir=download_dir)
Downloading ./ag_automm_tutorial/file.zip from https://automl-mm-bench.s3.amazonaws.com/petfinder_for_tutorial.zip...
100%|██████████| 18.8M/18.8M [00:00<00:00, 51.2MiB/s]
Next, we will load the CSV files.
import pandas as pd
dataset_path = download_dir + '/petfinder_for_tutorial'
train_data = pd.read_csv(f'{dataset_path}/train.csv', index_col=0)
test_data = pd.read_csv(f'{dataset_path}/test.csv', index_col=0)
label_col = 'AdoptionSpeed'
We need to expand the image paths to load them in training.
image_col = 'Images'
train_data[image_col] = train_data[image_col].apply(lambda ele: ele.split(';')[0]) # Use the first image for a quick tutorial
test_data[image_col] = test_data[image_col].apply(lambda ele: ele.split(';')[0])
def path_expander(path, base_folder):
path_l = path.split(';')
return ';'.join([os.path.abspath(os.path.join(base_folder, path)) for path in path_l])
train_data[image_col] = train_data[image_col].apply(lambda ele: path_expander(ele, base_folder=dataset_path))
test_data[image_col] = test_data[image_col].apply(lambda ele: path_expander(ele, base_folder=dataset_path))
train_data[image_col].iloc[0]
'/home/ci/autogluon/docs/tutorials/multimodal/multimodal_prediction/ag_automm_tutorial/petfinder_for_tutorial/images/7d7a39d71-1.jpg'
Each animal’s adoption profile includes pictures, a text description, and various tabular features such as age, breed, name, color, and more. Let’s look at an example row of data and display the text description and a picture.
example_row = train_data.iloc[0]
example_row
Type 2
Name Yumi Hamasaki
Age 4
Breed1 292
Breed2 265
Gender 2
Color1 1
Color2 5
Color3 7
MaturitySize 2
FurLength 2
Vaccinated 1
Dewormed 3
Sterilized 2
Health 1
Quantity 1
Fee 0
State 41326
RescuerID bcc4e1b9557a8b3aaf545ea8e6e86991
VideoAmt 0
Description I rescued Yumi Hamasaki at a food stall far aw...
PetID 7d7a39d71
PhotoAmt 3.0
AdoptionSpeed 0
Images /home/ci/autogluon/docs/tutorials/multimodal/m...
Name: 0, dtype: object
example_row['Description']
"I rescued Yumi Hamasaki at a food stall far away in Kelantan. At that time i was on my way back to KL, she was suffer from stomach problem and looking very2 sick.. I send her to vet & get the treatment + vaccinated and right now she's very2 healthy.. About yumi : - love to sleep with ppl - she will keep on meowing if she's hugry - very2 active, always seeking for people to accompany her playing - well trained (poo+pee in her own potty) - easy to bathing - I only feed her with these brands : IAMS, Kittenbites, Pro-formance Reason why i need someone to adopt Yumi: I just married and need to move to a new house where no pets are allowed :( As Yumi is very2 special to me, i will only give her to ppl that i think could take care of her just like i did (especially on her foods things).."
example_image = example_row[image_col]
from IPython.display import Image, display
pil_img = Image(filename=example_image)
display(pil_img)
Training#
Now let’s fit the predictor with the training data. Here we set a tight time budget for a quick demo.
from autogluon.multimodal import MultiModalPredictor
predictor = MultiModalPredictor(label=label_col)
predictor.fit(
train_data=train_data,
time_limit=120, # seconds
)
No path specified. Models will be saved in: "AutogluonModels/ag-20230302_162340/"
AutoMM starts to create your model. ✨
- Model will be saved to "/home/ci/autogluon/docs/tutorials/multimodal/multimodal_prediction/AutogluonModels/ag-20230302_162340".
- Validation metric is "roc_auc".
- To track the learning progress, you can open a terminal and launch Tensorboard:
```shell
# Assume you have installed tensorboard
tensorboard --logdir /home/ci/autogluon/docs/tutorials/multimodal/multimodal_prediction/AutogluonModels/ag-20230302_162340
```
Enjoy your coffee, and let AutoMM do the job ☕☕☕ Learn more at https://auto.gluon.ai
Downloading: "https://github.com/SwinTransformer/storage/releases/download/v1.0.0/swin_base_patch4_window7_224_22kto1k.pth" to /home/ci/.cache/torch/hub/checkpoints/swin_base_patch4_window7_224_22kto1k.pth
Start to fuse 3 checkpoints via the greedy soup algorithm.
AutoMM has created your model 🎉🎉🎉
- To load the model, use the code below:
```python
from autogluon.multimodal import MultiModalPredictor
predictor = MultiModalPredictor.load("/home/ci/autogluon/docs/tutorials/multimodal/multimodal_prediction/AutogluonModels/ag-20230302_162340")
```
- You can open a terminal and launch Tensorboard to visualize the training log:
```shell
# Assume you have installed tensorboard
tensorboard --logdir /home/ci/autogluon/docs/tutorials/multimodal/multimodal_prediction/AutogluonModels/ag-20230302_162340
```
- If you are not satisfied with the model, try to increase the training time,
adjust the hyperparameters (https://auto.gluon.ai/stable/tutorials/multimodal/advanced_topics/customization.html),
or post issues on GitHub: https://github.com/autogluon/autogluon
<autogluon.multimodal.predictor.MultiModalPredictor at 0x7f76b3aeea60>
Under the hood, AutoMM automatically infers the problem type (classification or regression), detects the data modalities, selects the related models from the multimodal model pools, and trains the selected models. If multiple backbones are available, AutoMM appends a late-fusion model (MLP or transformer) on top of them.
Evaluation#
Then we can evaluate the predictor on the test data.
scores = predictor.evaluate(test_data, metrics=["roc_auc"])
scores
{'roc_auc': 0.9419999999999998}
Prediction#
Given a multimodal dataframe without the label column, we can predict the labels.
predictions = predictor.predict(test_data.drop(columns=label_col))
predictions[:5]
8 0
70 1
82 1
28 0
63 1
Name: AdoptionSpeed, dtype: int64
For classification tasks, we can get the probabilities of all classes.
probas = predictor.predict_proba(test_data.drop(columns=label_col))
probas[:5]
| 0 | 1 | |
|---|---|---|
| 8 | 0.847337 | 0.152663 |
| 70 | 0.096791 | 0.903209 |
| 82 | 0.227008 | 0.772992 |
| 28 | 0.842669 | 0.157331 |
| 63 | 0.072571 | 0.927429 |
Note that calling .predict_proba() on one regression task will throw an exception.
Extract Embeddings#
Extracting embeddings can also be useful in many cases, where we want to convert each sample (per row in the dataframe) into an embedding vector.
embeddings = predictor.extract_embedding(test_data.drop(columns=label_col))
embeddings.shape
(100, 128)
Save and Load#
It is also convenient to save a predictor and re-load it.
Warning
MultiModalPredictor.load() uses pickle module implicitly, which is known to be insecure. It is possible to construct malicious pickle data which will execute arbitrary code during unpickling. Never load data that could have come from an untrusted source, or that could have been tampered with. Only load data you trust.
import uuid
model_path = f"./tmp/{uuid.uuid4().hex}-saved_model"
predictor.save(model_path)
loaded_predictor = MultiModalPredictor.load(model_path)
scores2 = loaded_predictor.evaluate(test_data, metrics=["roc_auc"])
scores2
Load pretrained checkpoint: /home/ci/autogluon/docs/tutorials/multimodal/multimodal_prediction/tmp/2d20407a80e64f02b5796de015478094-saved_model/model.ckpt
{'roc_auc': 0.9419999999999998}
Other Examples#
You may go to AutoMM Examples to explore other examples about AutoMM.
Customization#
To learn how to customize AutoMM, please refer to Customize AutoMM.
