Cloud Training with AWS SageMaker

To help with AutoGluon models training, AWS developed a set of training and inference deep learning containers. The containers can be used to train models with CPU and GPU instances and deployed as a SageMaker endpoint or used as a batch transform job.

The full end-to-end example is available in amazon-sagemaker-examples repository.

Pre-requisites

Before starting ensure that the latest version of sagemaker python API is installed via (pip install --upgrade sagemaker). This is required to ensure the information about newly released containers is available.

Training Scripts

To start using the containers, a user training script and the wrapper classes are required. When authoring a training/inference scripts, please refer to SageMaker documentation.

Here is one of the possible training scripts, which takes AutoGluon parameters as a YAML config and outputs predictions, models leaderboard and feature importance:

import argparse
import os
from pprint import pprint

import yaml
from autogluon.tabular import TabularDataset, TabularPredictor


def get_input_path(path):
    file = os.listdir(path)[0]
    if len(os.listdir(path)) > 1:
        print(f"WARN: more than one file is found in {channel} directory")
    print(f"Using {file}")
    filename = f"{path}/{file}"
    return filename


def get_env_if_present(name):
    result = None
    if name in os.environ:
        result = os.environ[name]
    return result


if __name__ == "__main__":
    # Disable Autotune
    os.environ["MXNET_CUDNN_AUTOTUNE_DEFAULT"] = "0"

    # ------------------------------------------------------------ Arguments parsing
    print("Starting AG")
    parser = argparse.ArgumentParser()

    # Data, model, and output directories
    parser.add_argument(
        "--output-data-dir", type=str, default=get_env_if_present("SM_OUTPUT_DATA_DIR")
    )
    parser.add_argument("--model-dir", type=str, default=get_env_if_present("SM_MODEL_DIR"))
    parser.add_argument("--n_gpus", type=str, default=get_env_if_present("SM_NUM_GPUS"))
    parser.add_argument("--training_dir", type=str, default=get_env_if_present("SM_CHANNEL_TRAIN"))
    parser.add_argument(
        "--test_dir", type=str, required=False, default=get_env_if_present("SM_CHANNEL_TEST")
    )
    parser.add_argument("--ag_config", type=str, default=get_env_if_present("SM_CHANNEL_CONFIG"))

    args, _ = parser.parse_known_args()

    print(f"Args: {args}")

    # See SageMaker-specific environment variables: https://sagemaker.readthedocs.io/en/stable/overview.html#prepare-a-training-script
    os.makedirs(args.output_data_dir, mode=0o777, exist_ok=True)

    config_file = get_input_path(args.ag_config)
    with open(config_file) as f:
        config = yaml.safe_load(f)  # AutoGluon-specific config

    if args.n_gpus:
        config["num_gpus"] = int(args.n_gpus)

    print("Running training job with the config:")
    pprint(config)

    # ---------------------------------------------------------------- Training

    train_file = get_input_path(args.training_dir)
    train_data = TabularDataset(train_file)

    ag_predictor_args = config["ag_predictor_args"]
    ag_predictor_args["path"] = args.model_dir
    ag_fit_args = config["ag_fit_args"]

    predictor = TabularPredictor(**ag_predictor_args).fit(train_data, **ag_fit_args)

    # --------------------------------------------------------------- Inference

    if args.test_dir:
        test_file = get_input_path(args.test_dir)
        test_data = TabularDataset(test_file)

        # Predictions
        y_pred_proba = predictor.predict_proba(test_data)
        if config.get("output_prediction_format", "csv") == "parquet":
            y_pred_proba.to_parquet(f"{args.output_data_dir}/predictions.parquet")
        else:
            y_pred_proba.to_csv(f"{args.output_data_dir}/predictions.csv")

        # Leaderboard
        if config.get("leaderboard", False):
            lb = predictor.leaderboard(test_data, silent=False)
            lb.to_csv(f"{args.output_data_dir}/leaderboard.csv")

        # Feature importance
        if config.get("feature_importance", False):
            feature_importance = predictor.feature_importance(test_data)
            feature_importance.to_csv(f"{args.output_data_dir}/feature_importance.csv")
    else:
        if config.get("leaderboard", False):
            lb = predictor.leaderboard(silent=False)
            lb.to_csv(f"{args.output_data_dir}/leaderboard.csv")

YAML config:

# AutoGluon Predictor constructor arguments
# - see https://github.com/awslabs/autogluon/blob/ef3a5312dc2eaa0c6afde042d671860ac42cbafb/tabular/src/autogluon/tabular/predictor/predictor.py#L51-L159
ag_predictor_args:
  eval_metric: roc_auc
  label: class

# AutoGluon Predictor.fit arguments
# - see https://github.com/awslabs/autogluon/blob/ef3a5312dc2eaa0c6afde042d671860ac42cbafb/tabular/src/autogluon/tabular/predictor/predictor.py#L280-L651
ag_fit_args:
  presets: "medium_quality_faster_train"
  num_bag_folds: 2
  num_bag_sets: 1
  num_stack_levels: 0

output_prediction_format: csv  # predictions output format: csv or parquet
feature_importance: true       # calculate and save feature importance if true
leaderboard: true              # save leaderboard output if true

Training

To train AutoGluon model, set up a SageMaker session:

import sagemaker

# Helper wrappers referred earlier
from ag_model import (
    AutoGluonTraining,
    AutoGluonInferenceModel,
    AutoGluonTabularPredictor,
)
from sagemaker import utils

role = sagemaker.get_execution_role()
sagemaker_session = sagemaker.session.Session()
region = sagemaker_session._region_name

bucket = sagemaker_session.default_bucket()
s3_prefix = f"autogluon_sm/{utils.sagemaker_timestamp()}"
output_path = f"s3://{bucket}/{s3_prefix}/output/"

Create a training task:

ag = AutoGluonTraining(
    role=role,
    entry_point="scripts/tabular_train.py",
    region=region,
    instance_count=1,
    instance_type="ml.m5.2xlarge",
    framework_version="0.4",
    py_version="py38",
    base_job_name="autogluon-tabular-train",
)

Upload the required inputs, via SageMaker session (in this case it is a training set, test set and training YAML config) and start the training job:

s3_prefix = f"autogluon_sm/{utils.sagemaker_timestamp()}"
train_input = ag.sagemaker_session.upload_data(
    path=os.path.join("data", "train.csv"), key_prefix=s3_prefix
)
eval_input = ag.sagemaker_session.upload_data(
    path=os.path.join("data", "test.csv"), key_prefix=s3_prefix
)
config_input = ag.sagemaker_session.upload_data(
    path=os.path.join("config", "config-med.yaml"), key_prefix=s3_prefix
)

job_name = utils.unique_name_from_base("test-autogluon-image")
ag.fit(
    {"config": config_input, "train": train_input, "test": eval_input},
    job_name=job_name,
)

Once the models are trained, they will be available in S3 location specified in ag.model_data field. The model is fully portable and can be downloaded locally if needed.

Conclusion

In this tutorial we explored how to train AutoGluon models using SageMaker. Learn how to deploy the trained models using AWS SageMaker - Deploying AutoGluon Models with AWS SageMaker or AWS Lambda - Deploying AutoGluon models with serverless templates.
